4 X 1 Thermal Transfer RFID Label | Alien Squiggle - ALN-9840 | RFT-4-1-ALN9840-5000-3
4 X 1 Thermal Transfer RFID Label | Alien Squiggle - ALN-9840 | RFT-4-1-ALN9840-5000-3
Part Number : RFT-4-1-ALN9840-5000-3
4 X 1 Thermal Transfer RFID Label | Alien Squiggle - ALN-9840 | EPC Class 1, Gen 2 * 96 bit * UHF * 915 MHz | Higgs EC | 4 Rolls Per Case | 5000 Labels Per Roll | 20000 Labels Per Case | Compatible With The Following Printers: Printronix T6000e / T4000 | Zebra ZT400 / ZT600 / R110xi4
LABEL SPECIFICATIONS
| Label Width | 4 Inches |
| Label Height | 1 Inches |
| Perforation | Yes |
| Adhesive | Permanent |
| Color | White |
| Wound | Out |
|---|---|
| Labels Across | 1 |
| Labels Per Roll | 5000 |
| Rolls Per Case | 4 |
| Labels Per Case | 20000 |
| Roll Diameter | 8 Inches |
| Core Diameter | 3 Inches |
| Weight Per Case | 24.0 lb |
| Minimum Quantity | 1 |
CHOOSING THE RIGHT LABEL
Packaging Info
This 4 X 1 Thermal Transfer RFID Label is for Printronix T6000e / T4000 | Zebra ZT400 / ZT600 / R110xi4 printers is packaged 4 rolls per case. Labelmatch offers this product by the single roll when available. Please contact Labelmatch customer service via Live Chat or at 1.800.726.7334. Our hours are 8:30am to 5:00pm EST.
Good to know
Alien Squiggle - ALN-9840 FEATURES -Powered by Alien®s volume focused Higgs™-EC UHF RFID IC and innovative Squiggle antenna design, the ALN9840 delivers industry leading EPC Gen 2 performance and reliability at a competitive price. -With its Higgs™-EC core, the Squiggle delivers next generation performance and a rich feature set, yet is completely optimized for the highest volume enterprise, retail, and apparel applications. -An optimized memory footprint includes a 32-bit TID, a 80- bit Unique TID for authentication and next generation serialization applications, a 128-bit EPC memory bank, 128-bits of user memory for distributed data applications, and password protected read and write support capabilities to prevent unauthorized viewing and modification of the tag’s data. -512-Bits of NVRAM Memory, up to 128-EPC Bits (nominally 96 bits), 128 User Bits, 80 Bit Unique TID, 32 Bit Access.
REcommendations
Alien Squiggle - ALN-9840 SUGGESTED APPLICATIONS -Volume Retail/Apparel -Enterprise Wide Asset Management -Warehouse Management -Tracking Challenging Materials and Objects
